Nozzle Measurement

If you can’t find a nozzle specific to your replica, you can determine the correct nozzle by measuring the two distances indicated below and adding them together. Then choose a nozzle from the list that is 0 to 0.5mm longer than your measurement.

Original Engine

With your original engine and nozzle still in the gearbox, measure the distance the nozzle extends from the front of the gearbox.

Wolverine Engine

With your Wolverine Airsoft engine in the gearbox, measure the distance from the front of the engine to the front of the gearbox and add it to your first measurement.
NozzleLength
CA LMG17.75
M24918.75
M419.25
AK19.65
KA FAL21.5
G3624.5
CA SCAR L25.75
PTS Masada27.5
VFC XCR29
A&K Masada33.32
GG SR2535.05
VFC SCAR H36
KA SIG 55647.4
